Product Details
| Technical Data Sheet | ||||
| Frequency Range | 160~430MHz | Finish | Natural Conductive Oxidation | |
| Insertion Loss | ≤0.8dB
(Above 6.02dB Split) |
Connector Body | Brass, Tri-Alloy Plate | |
| VSWR | Input ≤1.30:1
Output ≤1.20:1 |
Housing | Aluminum, 6061 T6
Clear Chem Conversion Film |
|
| Isolation | ≥22dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Amplitude Balance | ≤±0.2dB | Solder | Lead Free, RoHS Compliant | |
| Phase Balance | ≤±2° | Operating Temperature | -55～+85℃ | |
| 1Power Handling | Forward ≤50Watt;
Reversed ≤1Watt |
|
Operating Humidity | Up to 95%,Non- Condensing |
| Impedance | 50Ω | Weight | ||
| Port Connectors | N-Female | |||
