Product Details
| Technical Data Sheet | ||||
| Frequency Range | 2.7~3GHz | Finish | Painted Blue_ RAL #5007 | |
| Insertion Loss | ≤0.3dB (Excl. Coupling Loss 0.01dB) | Connector Body | Passivated Stainless Steel | |
| Coupling Factor | ≤30±0.8dB | Housing | Aluminum, 6061 T6 Clear Chem Conversion Film | |
| Coupling Sensitivity | ≤±0.15dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Directivity | ≥25dB | Solder | Lead Free, RoHS Compliant | |
| VSWR | Primary ≤1.15:1 Secondary ≤1.15:1 | Operating Temperature | -55～+85℃ | |
| 1Power Handling | Incident ≤50Watt; Reflected ≤2Watt | Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 30g | |
| Port Connectors | SMA-Female | |||
1Power Handling guaranteed when load’s VSWR within 1.50:1.
