Product Details
Features
Ultra-Wideband,High Reliability
Low Insertion Loss,Low VSWR, High Power Handling
Electrical specifications
| Frequency Range | 0.8~2.5GHz |
| Coupling | 3.1±0.5dB |
| Isolation | ≥20dB |
| VSWR | ≤ 1.30:1 |
| Frequency Sensitivity | ≤±0.5dB |
| Phase Balance | ——– |
| Power Handling | ≤200Watt |
| Impedance | 50Ω |
| Port Connectors | SMA-Female |
| Surface Color | Black |
| Wight | 210g |
Environmental Parameters
Operating Temperature -40～+70℃
Operating Humidity Up to 90%,Non- Condensing
