Product Details
| Technical Data Sheet | ||||
| Frequency Range | 8~12GHz | Finish | Painted Blue_ RAL #5007 | |
| Insertion Loss | ≤1.0dB (Excl. Coupling
Loss 0.92dB) |
Connector Body | Passivated Stainless Steel | |
| Coupling Factor | ≤10±1dB | Housing | Aluminum, 6061 T6
Clear Chem Conversion Film |
|
| Coupling Sensitivity | ≤±0.7dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Directivity | ≥20dB | Solder | Lead Free, RoHS Compliant | |
| VSWR | Primary ≤1.35:1
Secondary ≤1.35:1 |
Operating Temperature | -55～+85℃ | |
| 1Power Handling | Incident ≤20Watt;
Reflected ≤20Watt |
Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 70g | |
| Port Connectors | SMA-Female | |||
